Details
Racing, gravel-grinding, commuting or wicked-weather training - the Cross covers them all. The A6-SL aluminum frame is a class-leading 1300g that is perfect for hopping barriers or stomping up the steepest run-ups. Light as it is, the Cross delivers when you put the power down even in the sloppiest conditions and deepest sand pits. Lightweight, fast and stable, the Cross is here to take you to your next podium.
- A6-SL super-butted 6066 aluminum frame
- FC-440 full-carbon fork
- SRAM Force CX-1 gearing
- Oval Concepts 723 disc wheelset
- SRAM Force CX-1 flat-mount disc brakes
- Thru-axles front and rear
- Internal cable routing
- CX geometry with higher bottom bracket
- Hidden fender eyelets on the fork
Pedals sold separately
Specs
Frame | A6-SL super-butted 6066 aluminum w/ shaped top tube & integrated tapered head tube w/ 1 1/2” lower, PF30 shell, double water bottle mounts, forged dropouts w/ flat-mount disc system, 12mm convertible thru-axle system w/ replaceable hanger |
---|---|
Fork | FC-440 Cross carbon monocoque, 12mm thru-axle w/ flat-mount disc system, tapered steerer |
Headset | FSA, 1 1/8” upper - 1 1/2” lower, integrated |
Axles |
Front: 100 x 12mm Rear: 142 x 12mm |
Rims/Wheels | Oval Concepts 723 Disc, 700c 24/28H tubeless compatible |
Tires | Challenge Grifo 700 x 33c, 60tpi, folding |
Crankset | Quark Prime Carbon |
Chainrings | 42T, Power ready |
Bottom Bracket | SRAM, PF30 |
Chain | KMC X11 w/ MissingLink |
Rear Derailleur | SRAM Force CX-1 |
Cassette/Rear Cogs | SRAM PG-1170, 11-32T |
Shifters | SRAM Force1 Hydraulic, 11-speed |
Handlebars | Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp, 133mm drop, 4° sweep |
Tape/Grips | Anti-Slip Silicone |
Stem | Oval Concepts 313, 3D-forged 6061 stem body, +/-7° |
Brake Levers | SRAM Force CX-1 DoubleTap w/ Hydraulic reservior |
Brakes | SRAM Force CX-1 Hydraulic, 160 / 140 rotors |
Saddle | Oval Concepts X38 with pressure relief zone, cromo rail |
Seat Post | Oval Concepts 905, carbon & alloy, 27.2mm diameter |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Purple / 56cm | 785749164793 | 1791667656 | 210000000809 |
